Dared GIDC, Jamnagar, GujaratBrass parts since 1992
Earthing & Lightning Protection

Earth Clamp Manufacturer

Earth clamps that join grounding conductors to earth rods, pipes and structural steel, in brass, copper, aluminium and gunmetal.

Call +91 288 2731181
Brass U-bolt rod to cable earth clamp by Empire Alloys

Overview

An earth clamp is the mechanical link between the earthing conductor and the electrode. When a fault happens, current has to pass through that clamp into the ground, so a loose or corroded clamp can defeat the whole earthing system.

Empire Alloys manufactures earth clamps from high-conductivity metals: brass, copper, aluminium and gunmetal. Because the company runs its own foundry, extrusion press and forging presses, clamp bodies can be cast, forged or machined depending on the design and quantity.

The range below covers the common clamp styles. For specific rod and tape sizes see the rod to tape clamp and rod to cable clamp pages.

Types and variants we make

Brass earth clamps

General-purpose clamps for rods and pipes.

Copper rod to tape clamps

Join copper tape to earth rods.

U-bolt earth clamps

U-bolt pattern for rod-to-cable joints.

Heavy-duty ground clamps

Larger bodies for high fault currents.

Aluminium earth clamps

For aluminium conductors.

Tower earth clamps

For transmission and telecom towers.

Specifications

MaterialsBrass, copper, aluminium, gunmetal
ProcessCasting, forging, CNC machining
FinishNatural, tin or nickel plated, as required
CustomisationRod size, conductor size and bolt pattern to drawing

Values shown are typical capabilities. Final dimensions, threads, tolerances and finish are confirmed against your drawing or sample at quotation stage.

Why buyers specify these parts from Empire Alloys

  • In-house brass extrusion and copper-alloy foundry
  • Forged bodies for strength where required
  • Threads checked with ring and plug gauges
  • Over 30 years in non-ferrous parts

Applications

  • Building earthing
  • Substations
  • Telecom towers
  • Solar plants
  • Lightning protection systems
  • Industrial plant earthing

Materials, plating and packing

Free-cutting brass (CZ121 / IS 319 type) is the default for machined parts; copper, copper alloys, aluminium, gunmetal and steel are also processed in-house. Plating options at Empire Alloys include tin, copper, chrome, nickel and zinc, with shot blasting and nitric wash available as surface treatments.

Parts are packed to suit the shipment: PVC or thermal PVC bags, cartons, shrink-wrap, strapped wooden cases or pallets, with every bag and carton labelled for easy identification.

What to send with your enquiry

  • Drawing (PDF/DWG/STEP) or a physical sample, plus the part name or code you use
  • Material grade and any standard the part must meet
  • Thread type and size, critical dimensions and tolerance
  • Finish or plating, quantity per lot and annual requirement
  • Packing preference and delivery location (India or export)

Frequently asked questions

Which material should I choose for an earth clamp?

Copper and gunmetal suit buried or corrosive locations; brass is economical for protected or above-ground connections; aluminium is used with aluminium conductors.

Do you make clamps for 5/8 inch rods?

Yes. Our rod to tape clamps are listed for 5/8" rods, and other rod sizes are made to order.

Can you supply earthing kits?

Clamps can be supplied with matching earth bars, earth blocks and test clamps.
