Split Bolts & Connectors

Brass Split Bolt Connector

Brass-bodied split bolts for grounding, splicing and tapping conductors where a machinable, corrosion-resistant connector is preferred over copper.

Call +91 288 2731181
Brass split bolt connectors with hex nut made by Empire Alloys

Overview

Brass split bolt connectors follow the same principle as copper split bolts: a slotted bolt holds the conductors, and a nut draws a pressure bar down onto them. Brass is chosen when the buyer wants a part that machines cleanly, takes plating well and resists corrosion in panels, earthing pits and outdoor boxes.

Empire Alloys turns and forges brass split bolts from rod produced on its own extrusion press, which keeps material consistent between lots. Sizes are matched to the conductor diameters the customer uses, and threads, nut style and plating follow the drawing or sample supplied.

For high-current line taps where conductivity matters most, see our copper-alloy split bolt wire connectors; for line-tap duty, see split bolt line tap connectors.

Types and variants we make

Standard brass split bolts

Hex-nut split bolts for common conductor diameters.

Split bolts with spacer/pressure bar

Bar between conductors for an even clamping force.

Nickel or tin-plated brass split bolts

Plated for appearance and added corrosion protection.

Drawing-specific brass split bolts

Special lengths, threads or markings to your design.

Specifications

MaterialFree-cutting brass or customer-specified brass grade
Conductor compatibilityCopper conductors; other combinations by enquiry
ThreadMetric, UNC, UNF or custom
FinishNatural brass, nickel or tin plated
ProcessHot forging / CNC turning, threading, inspection

Values shown are typical capabilities. Final dimensions, threads, tolerances and finish are confirmed against your drawing or sample at quotation stage.

Why buyers specify these parts from Empire Alloys

  • Brass rod from the company’s own 400 MT extrusion press
  • Clean threads cut or rolled on CNC and special-purpose machines
  • Plating and packing handled in the same supply chain
  • Sizes from small panel parts to heavy grounding connectors

Applications

  • Earthing pits and grounding conductors
  • Control panel wiring
  • Telecom earthing
  • Lightning protection down conductors
  • Splicing in junction boxes

Materials, plating and packing

Free-cutting brass (CZ121 / IS 319 type) is the default for machined parts; copper, copper alloys, aluminium, gunmetal and steel are also processed in-house. Plating options at Empire Alloys include tin, copper, chrome, nickel and zinc, with shot blasting and nitric wash available as surface treatments.

Parts are packed to suit the shipment: PVC or thermal PVC bags, cartons, shrink-wrap, strapped wooden cases or pallets, with every bag and carton labelled for easy identification.

What to send with your enquiry

  • Drawing (PDF/DWG/STEP) or a physical sample, plus the part name or code you use
  • Material grade and any standard the part must meet
  • Thread type and size, critical dimensions and tolerance
  • Finish or plating, quantity per lot and annual requirement
  • Packing preference and delivery location (India or export)

Frequently asked questions

Is brass or copper better for a split bolt?

Copper alloy gives higher conductivity and is the usual choice for line taps. Brass is preferred where machinability, appearance or cost matter and current is moderate. We make both.

Can you match an existing split bolt sample?

Yes. Send a sample or drawing and we will confirm material, dimensions and plating before quoting.

What is the minimum order?

It depends on size and finish. Share your quantity in the enquiry and the sales team will confirm.
